Centek CT-1701
Данная инструкция на русском языке предназначена для холодильника Centek CT-1701, описывает принцип работы и основные моменты эксплуатации устройства. Перед первым включением рекомендуется внимательно изучить данное руководство.
Инструкция для холодильника представлена в формате PDF, который поддерживается на всех современных устройствах, так что сложностей с открытием файла возникнуть не должно. Но если открыть документ не получается, установите любую программу для чтения PDF файлов, например Acrobat Reader.
Чтобы распечатать инструкцию, нужно ее сначала скачать, для этого кликните по кнопке «Скачать инструкцию», файл откроется в новой вкладке, затем нажмите комбинацию клавиш Сtrl + P и из открывшегося диалогового окна, отправьте документ на печать.
18
OVERHANGING DOORS
Attention
For rearranging the door, it is recommended to contact a qualified specialist. If you decide to reinstall the refrigerator
door yourself, use the recommendations listed below in this manual.
Necessary tools: phillips screwdriver, flat screwdriver, hex wrench.
1. In order to re-hinge the refrigerator door to the opposite side and change its opening direction, follow the instructions below.
The set of parts numbered “3”, “4”, “5” and “6” should be transferred to the opposite side of the refrigerator. To do so, with the glass door of the
refrigerator closed, remove the plugs “1” and “2”. Remove plug “3”, unscrew bolts “4” and “6” and remove the hinge “5”.
2. Open the refrigerator door and very carefully pull out the glass door.
3. Remove the door hinge plug “6” on the bottom side of the glass door, the retaining screws of the door stop mechanism “8” and the door stop mechanism
“7”, then fasten them on the opposite side of the refrigerator in the same way.
4. Disassemble the adjustable foot “11”, remove set screws “4” and the lower hinge “10”, then swap the parts between the two sides and reassemble the
adjustable foot, lower hinge and set screws in a reverse order.
5. Install the glass door on the lower hinge and fasten the upper hinge “5”. Align the door with the refrigerator body and check tightness of the seal,
then reinstall all parts “2” and “3”.
12
3
4
5
6
6
7
8
11
③
⑤②
4
10
11
3
52
VENTILATION
The compressor and condenser of the refrigerator heat up during operation, so it is necessary to provide sufficient ventilation to the device.
1. The refrigerator should be installed in a well-ventilated room with normal humidity. It is forbidden to install a refrigerator in rooms with high humidity,
for example, in bathrooms, basements.
2. When installing, ensure minimum gaps (3-5 cm) on the sides of the device and 10 cm on top for free air circulation. Do not block the air movement at
the back of the appliance.
3. Do not place near heat sources.
4. Do not place the refrigerator in direct sunlight or near heat sources (kitchen stoves, ovens, fireplaces).
ALIGNMENT
For the efficient operation of the refrigerator, it is important that it is on a flat surface. After installing the refrigerator in place, adjust its position by
rotating the adjustment supports in its front part. The tilt of the refrigerator back should not exceed 5°.
CONNECTION TO THE POWER SUPPLY
The refrigerator corresponds to the 1st class of protection against electric shock and is connected to the electrical supply using a two-pole outlet with
a grounding contact.
- Before connecting to the mains, make sure that:
- The mains voltage corresponds to the data indicated on the special plate on the back of the refrigerator;
- The grounding contact of the electrical outlet is connected to the grounding wire of the power supply cable of the electrical network (the connecting
wire must be designed for a current of at least 10 A);
- The socket and plug are of the same type; if the plug does not fit into the outlet, the outlet should be replaced with the corresponding plug of the power
cord (the work must be performed by a qualified electrician).
The refrigerator must be installed in such a way that you always have access to an outlet. A refrigerator connected in violation of the safety requirements
of high-power household appliances described in this manual is potentially dangerous.
The manufacturer is not responsible for damage to health and property if it is caused by non-compliance with the specified installation standards.
5. REFRIGERATOR OPERATION
BEFORE SWITCHING ON
It is necessary to connect the refrigerator to the mains three hours after its installation. Thus, the refrigerant will be distributed properly after
transportation – this is necessary for the proper operation of the refrigerator.
