Centek CT-1767
Данная инструкция на русском языке предназначена для холодильника Centek CT-1767, описывает принцип работы и основные моменты эксплуатации устройства. Перед первым включением рекомендуется внимательно изучить данное руководство.
Инструкция для холодильника представлена в формате PDF, который поддерживается на всех современных устройствах, так что сложностей с открытием файла возникнуть не должно. Но если открыть документ не получается, установите любую программу для чтения PDF файлов, например Acrobat Reader.
Чтобы распечатать инструкцию, нужно ее сначала скачать, для этого кликните по кнопке «Скачать инструкцию», файл откроется в новой вкладке, затем нажмите комбинацию клавиш Сtrl + P и из открывшегося диалогового окна, отправьте документ на печать.
10
1. SECURITY MEASURES
In order to avoid situations that are dangerous to life and health, as
well as premature failure of the device, it is necessary to strictly
observe the following conditions:
-
ATTENTION! Non-observance of the following safety instructions
can cause accidents.
-Use only 220-240V, 50Hz power supply systems.
-
Avoid using socket adapters and extension cables for power con-
nection.
-
Do not store volatile, flammable or explosive substances, such as
ether, ethanol, gasoline, etc. in the freezer.
-Do not place heavy objects or spill water on the freezer.
-
If you notice any unusual noise, smell, smoke or any signs of damage
during operation, immediately disconnect the appliance from power
supply and contact a maintenance service.
-Avoid damaging the power cable:
-No power cable replacement is allowed.
-Do not place heavy objects on the power cable.
-Keep the power cable at a safe distance from heat sources.
-
Disconnect the appliance from power supply by puling the plug
and not the cable.
-
Do not connect too many appliances to the same power supply
circuit as this can become the cause of a fire.
-
Wipe the internal surface of the appliance with a soft cloth damp-
ened with warm water.
-
Do not touch the internal walls of the appliance and the foods stored
inside with wet hands.
-
It is necessary to maintain air circulation around the appliance
during its operation. The minimum distance between the appliance
and adjacent walls should be 10 cm.
-
Before connecting the appliance to power supply let it stand up-
right for 2 hours. This will reduce the probability of cooling system
malfunctions caused by improper transportation.
-
The refrigerant used in the appliance is charged into it at the factory
using special equipment. Do not allow refrigerant circulation piping
to get damaged.
-
The refrigerant escaping from the piping can ignite or harm your
health. If the refrigerant circuit is damaged, avoid using open flames
or any other sources of ignition and ventilate the room where the
freezer is installed for several minutes.
-
The appliance should not be used by physically, sensory or mentally
handicapped persons (including children) or by persons without
sufficient experience or knowledge, unless such persons are under
supervision, or have been instructed on the use of the appliance,
by the persons responsible for their safety.
-
Hoarfrost or condensation may appear on the appliance’s walls
when the ambient temperature and humidity is very high; wipe
them with a dry cloth.
-
In case of power cable damage it should be replaced, to avoid
dangerous situations, by the Manufacturer, a service centre or
similar skilled personnel.
-
Never turn the appliance on if it shows any signs of damage. If
you are in doubt about the functionality of the appliance, contact
a maintenance service.
2. TECHNICAL SPECIFICATION
Model СТ-1766 СТ-1767
Climate zone SN/N/ST/T
Max. power rating, W 255 250
Freezer chamber capacity, l 368 418
Freezer chamber temperature in
freezing mode
-12 ... -24 °С
Freezer chamber temperature in
refrigerator mode
0 ... 10 °С
Rated voltage 220-240 V ~50 Hz
Current, А 1,13 1,5
Noise level, dB 44
Power consumption, kW/24 h 0,832 0,912
Power consumption class А+
Refrigerant R600 (80 g) R600 (90 g)
Net weight, kg 50 54,5
Size (w/d/h), mm 1255
745
825
1416
750
825
3. SCOPE OF SUPPLY
-Chest freezer - 1 pc.
-Food storage bin - 4 pcs.
-Ice scraper - 1 pc.
-User Manual - 1 pc.
4. APPLIANCE DESCRIPTION
1. Lid handle
2. Food storage bin
3. Power cable
4. Grille
5. Control panel
6. Freezer housing
7. Drainage opening
5. APPLIANCE INSTALLATION
-
The appliance should be transported in an upright position. Do not
turn the appliance over. Tilting the appliance by more than 45
0
is
not allowed.
-
This appliance should not be built into furniture or operated in
niches.
-
Do not install the appliance in facilities with very high temperature
and humidity.
-
A minimum space of 10 cm shall be left between the rear and side
walls of the freezer and adjacent walls to provide for proper air
circulation.
-
Install the appliance in a place protected from direct sunlight and
heat sources. Direct sunlight can impact the acrylic coating and
heat sources cause increase power consumption. Very low ambient
temperatures can also cause improper operation of the appliance.
-
After connecting the appliance to power supply, it should operate
empty for 2 to 3 hours to cool down sufficiently before placing
food in it.
ATTENTION! The device can be used in an unheated room at a
temperature of -15 0C.
