27
OVERHANGING DOORS
ATTENTION!
For rearranging the door, it is recommended to contact a qualified
specialist. If you decide to reinstall the refrigerator door yourself,
use the recommendations listed below in this manual.
Tools required: Philips screwdriver, flat screwdriver, Allen key.
–Remove the cap from the top hinge.
–Remove the top loop. Disconnect the power cable of the
displaying.
–Open the top door and carefully lift it up. The door should come
off the hinge and completely disengage from refrigerator.
–Use a screwdriver to remove the middle hinge.
–Remove the freezer door.
–Use a screwdriver to remove the hinge on the bottom
refrigerator parts. Turn over the hinge mount and reinstall
the hinge as shown in the figure below and install him to the
opposite side.
–Install the freezer door on the bottom hinge.
–Use a screwdriver to install the middle hinge on the same side
as the bottom loop.
–Place the upper door on the middle hinge. Connect display
power cable.
–Use a screwdriver to install the top hinge, on the same side
as the rest.
–Place a cap on top of the hinge.
VENTILATION
The compressor and condenser of the refrigerator heat up during
operation, so it is necessary to provide sufficient ventilation to
the device.
–The refrigerator should be installed in a well-ventilated room
with normal humidity. It is forbidden to install a refrigerator
in rooms with high humidity, for example, in bathrooms,
basements.
–When installing, ensure minimum gaps (3-5 cm) on the sides of
the device and 10 cm on top for free air circulation. Do not block
the air movement at the back of the appliance.
–Do not place near heat sources.
–Do not place the refrigerator in direct sunlight or near heat
sources (kitchen stoves, ovens, fireplaces).
ALIGNMENT
For the efficient operation of the refrigerator, it is important that
it is on a flat surface. After installing the refrigerator in place,
adjust its position by rotating the adjustment supports in its front
part. The tilt of the refrigerator back should not exceed 5°.
CONNECTION TO THE POWER SUPPLY
The refrigerator corresponds to the 1st class of protection against
electric shock and is connected to the electrical supply using a
two-pole outlet with a grounding contact.
–Before connecting to the mains, make sure that:
–The mains voltage corresponds to the data indicated on the
special plate on the back of the refrigerator;
–The grounding contact of the electrical outlet is connected to
the grounding wire of the power supply cable of the electrical
network (the connecting wire must be designed for a current
of at least 10 A);
–The socket and plug are of the same type; if the plug does
not fit into the outlet, the outlet should be replaced with the
corresponding plug of the power cord (the work must be
performed by a qualified electrician).
The refrigerator must be installed in such a way that you always
have access to an outlet. A refrigerator connected in violation
of the safety requirements of high-power household appliances
described in this manual is potentially dangerous.
The manufacturer is not responsible for damage to health and
property if it is caused by non-compliance with the specified
installation standards.
5. REFRIGERATOR OPERATION
5.1. BEFORE SWITCHING ON
It is necessary to connect the refrigerator to the mains three
hours after its installation. Thus, the refrigerant will be
distributed properly after transportation – this is necessary for
the proper operation of the refrigerator.
A few hours after connecting the refrigerator to the mains, You
can put products in it.
Remove the transport spacers between the compressor and the
back wall of the niche, as well as other spacers and adhesive
tapes that keep the moving parts of the device from shifting.
If the device has a protective coating of polymer film, carefully
remove it, taking precautions not to damage the paint or polymer
coating of the parts.
5.2. BEGINNING OF WORK
- When you turn on the power of the refrigerator, the display
screen is displayed for 3 seconds. The start tone will sound and
the screen will then return to the standard operation display.
- When using the refrigerator for the first time, the temperature
of the refrigerator compartment is 5 °C, the freezer compartment
is -18 °C.
- When an error occurs, an error code is shown on the display
(see error code table). During normal operation, the display shows
the set temperature of the refrigerator or freezer compartment.
LOCK/UNLOCK
- In the unlocked state, press and hold the lock button (3) for 3
seconds, the indicator (F) will light up and a beep will sound -
this means that the display panel is locked, the device cannot be
controlled at the moment.
- In the locked state, press and hold the lock button (3) for 3
seconds, the indicator (F) will go out and a beep will sound - this
means that the display panel is unlocked, at which time control of
the device is available.
SETTING THE TEMPERATURE IN THE REFRIGERATOR COMPARTMENT
Press the Fridge button (1) to set the temperature in the
refrigerator compartment. Each time you press the button, the
temperature will decrease by 1 ⁰C. Temperature setting range
from 2 to 8 ⁰С. When the temperature reaches 2 ⁰С, press button (1)
again, the value will change to 8 ⁰С.
ACTIVATING THE «FAST COOLING» MODE
To activate the Fast Cool mode, press and hold the Fridge button (1)
for 3 seconds. The mode indicator (C) will light up on the display
and the temperature in the refrigerator compartment will drop
to 2 ⁰C. To exit the mode, press and hold the button again for 3
seconds. The indicator (C) will go off. The mode will automatically
exit after 6 hours.
