Centek CT-1743
Данная инструкция на русском языке предназначена для холодильника Centek CT-1743, описывает принцип работы и основные моменты эксплуатации устройства. Перед первым включением рекомендуется внимательно изучить данное руководство.
Инструкция для холодильника представлена в формате PDF, который поддерживается на всех современных устройствах, так что сложностей с открытием файла возникнуть не должно. Но если открыть документ не получается, установите любую программу для чтения PDF файлов, например Acrobat Reader.
Чтобы распечатать инструкцию, нужно ее сначала скачать, для этого кликните по кнопке «Скачать инструкцию», файл откроется в новой вкладке, затем нажмите комбинацию клавиш Сtrl + P и из открывшегося диалогового окна, отправьте документ на печать.
19
Digital display
Temperature indicator
ECO ECO
Fast
cooling function indicator "Fast cooling"
Fast
freezing function indicator "Fast freezing"
Vegetables function indicator "Vegetables" mode
Fruit indicator "Fruits"
Chill mode indicator "Cold" mode indicator
4. INSTALLING THE REFRIGERATOR
Correct installation of the refrigerator is essential for its reliable and efficient operation.
Always lift the refrigerator grabbing it by the bottom. Never drag the refrigerator by its door
or door handle. The manufacturer’s guarantee will not apply to door damage caused by its re-
hinging. Any repairs caused by such circumstances will be performed at the cost of the owner.
4.1. VENTILATION
The compressor and condenser of the refrigerator heat up during operation, therefore
sufficient ventilation should be provided for cooling.
–The refrigerator should be installed in a well-ventilated room with normal humidity. Never
install the refrigerator in rooms with high humidity, e.g. in bathrooms or basements.
–Ensure that gaps of at least 3 to 5 cm on the sides and 10 cm above the top are provided
during installation for free air circulation. Do not obstruct air movement at the back side
of the appliance.
–Do not place the appliance near heat sources.
–Do not install the refrigerator so that it is exposed to direct sunlight or near heat sources
(kitchen ovens, cookers, fireplaces, etc.).
4.2. LEVELING
It is important that the refrigerator is installed on a level surface for efficient operation. After
placing the refrigerator at its permanent location adjust its position by turning the adjustable
front feet. The refrigerator should not be slanted backwards by more than 5°.
4.3. CONNECTING TO POWER SUPPLY
The refrigerator complies with Class 1 requirements for protection against electric shock and
is connected to the power supply grid by a two-pole plug with an earthing contact. Before
connecting to power supply ensure that:
–the grid voltage corresponds to that indicated on the data plate located on the back side
of the refrigerator;
–the earthing contact of the electric socket is connected to an earthing conductor of the
mains cable (the earthing conductor should have a minimum rating of 10 A);
–the power socket and plug should be of the same type; if the plug does not fit the socket the
latter should be replaced with one compatible with the plug (this work should be performed
by a skilled electrician).
The refrigerator should be placed so that you would always have access to the power socket. A
refrigerator improperly connected to power supply, i.e. incompliant with the requirements for
powerful home appliances set forth in this manual, is potentially dangerous. The manufacturer
shall not be made liable for damage to human health and property if such damage is caused
by non-observance of the installation requirements specified herein.
5. OPERATING THE REFRIGERATOR
5.1. BEFORE TURNING ON
After installing the refrigerator please wait for approx. three hours before connecting
it to power supply. This way you will allow the refrigerant to be properly distributed: this
is necessary for proper operation of the refrigerator. You will be able to place food in the
refrigerator within a few hours after connecting it to power supply. Remove the transportation
inserts between the compressor and the back wall of the niche, as well as all other inserts
and adhesive tape preventing the movable parts of the appliance from displacement during
transportation.
If the appliance is covered in a protective polymer film, carefully remove it, taking precautions
not to damage the paint or polymer coatings in the components.
5.2. INITIAL OPERATION
DISPLAY
When the refrigerator is powered on, the display screen is displayed for 5 seconds.
After closing the refrigerator door, the display will automatically turn off if no button is
pressed for 3 minutes.
When the display is turned off, it lights up when the refrigerator door is opened or any button
is pressed.
The following button operations are valid only if the buttons are unlocked and lit on the display.
SETTING THE TEMPERATURE IN THE REFRIGERATOR
Press the REFRIGERATOR button to select the refrigerator area, and the whole digit on the
display will start flashing, then press the REFRIGERATOR button to adjust the whole value, then
press OK to confirm the setting. Then the decimal digit will start flashing. Press the FRIDGE
button to adjust the decimal value, finally after that press OK to confirm the setting.
The temperature conditions of the refrigerator change as follows:
5 °C => 6 °C => 7 °C => 8 °C => OFF => 2 °C => 3 °C => 4 °C => 5 °C.
OFF means turning off the refrigerator. When the OFF value is selected, the refrigerator will
turn off, the «°C» icon will go out.
ATTENTION! Before enabling this feature, be sure to remove all products from the fresh food
compartment.
SETTING THE TEMPERATURE IN THE FREEZER
Press the FREEZER button to select the refrigerator area, and the whole digit on the display
will start flashing, then press the FREEZER button to adjust the whole value, then press OK to
confirm the setting. Then the decimal digit will start flashing. Press the FREEZER button to
adjust the decimal value, finally after that press OK to confirm the setting.
The temperature conditions of the refrigerator change as follows:
-18 °C => -17 °C => -16 °C => -24 °C => -23 °C => -22 °C => -21 °C => -20 °C => -19 °C => -18 °C.
SETTING THE TEMPERATURE OF CARE+
Press the Care+ button to adjust the temperature in the temperature-controlled chamber
(6) until the desired temperature mode is selected, then press and hold the OK button for
5 seconds to confirm the setting, while the current mode indicator will stop flashing. The
temperature modes of the Care+ camera are as follows:
Vegetables => Fruits => Cold => Vegetables.
When the temperature in the refrigerator is set to OFF, the Care+ mode is turned off.
NOTE: It is not possible to press the Care+ button when the refrigerator temperature is set
to OFF mode.
ECO FUNCTION
When the ECO function is enabled, the temperature in the refrigerator will be set to 5 °C, and
in the freezer - to -18 °C, which guarantees the storage of products in the best temperature
range, as well as more efficient operation of the refrigerator.
In ECO mode, the temperature in the refrigerator and freezer does not change.
Activation of ECO mode:
Press the function selection button (10) until the ECO indicator starts flashing, then press
and hold the OK button for 5 seconds to confirm the setting, the ECO indicator lights up
continuously.
Exiting ECO mode:
While the ECO function is active, press the function selection button (10) until the ECO indicator
flashes, then press and hold the OK button for 5 seconds to confirm the setting and turn off the
ECO function, the ECO indicator turns off, and the temperature in the chambers is restored to
the one that was set before switching on ECO functions (not in functional state).
NOTE: During the activation of the «Fast Freezing» or «Fast Cooling» function, the ECO function
is automatically turned off.
«FAST COOLING» FUNCTION
