Centek CT-1722
Данная инструкция на русском языке предназначена для холодильника Centek CT-1722, описывает принцип работы и основные моменты эксплуатации устройства. Перед первым включением рекомендуется внимательно изучить данное руководство.
Инструкция для холодильника представлена в формате PDF, который поддерживается на всех современных устройствах, так что сложностей с открытием файла возникнуть не должно. Но если открыть документ не получается, установите любую программу для чтения PDF файлов, например Acrobat Reader.
Чтобы распечатать инструкцию, нужно ее сначала скачать, для этого кликните по кнопке «Скачать инструкцию», файл откроется в новой вкладке, затем нажмите комбинацию клавиш Сtrl + P и из открывшегося диалогового окна, отправьте документ на печать.
25
the hinge as shown in the figure below and install him to the
opposite side.
–Install the freezer door on the bottom hinge.
–Use a screwdriver to install the middle hinge on the same side
as the bottom loop.
–Place the upper door on the middle hinge. Connect display
power cable.
–Use a screwdriver to install the top hinge, on the same side
as the rest.
–Place a cap on top of the hinge.
VENTILATION
The compressor and condenser of the refrigerator heat up during
operation, so it is necessary to provide sufficient ventilation to
the device.
–The refrigerator should be installed in a well-ventilated room
with normal humidity. It is forbidden to install a refrigerator
in rooms with high humidity, for example, in bathrooms,
basements.
–When installing, ensure minimum gaps (3-5 cm) on the sides of
the device and 10 cm on top for free air circulation. Do not block
the air movement at the back of the appliance.
–Do not place near heat sources.
–Do not place the refrigerator in direct sunlight or near heat
sources (kitchen stoves, ovens, fireplaces).
ALIGNMENT
For the efficient operation of the refrigerator, it is important that
it is on a flat surface. After installing the refrigerator in place,
adjust its position by rotating the adjustment supports in its front
part. The tilt of the refrigerator back should not exceed 5°.
CONNECTION TO THE POWER SUPPLY
The refrigerator corresponds to the 1st class of protection against
electric shock and is connected to the electrical supply using a
two-pole outlet with a grounding contact.
–Before connecting to the mains, make sure that:
–The mains voltage corresponds to the data indicated on the
special plate on the back of the refrigerator;
–The grounding contact of the electrical outlet is connected to
the grounding wire of the power supply cable of the electrical
network (the connecting wire must be designed for a current
of at least 10 A);
–The socket and plug are of the same type; if the plug does
not fit into the outlet, the outlet should be replaced with the
corresponding plug of the power cord (the work must be
performed by a qualified electrician).
The refrigerator must be installed in such a way that you always
have access to an outlet. A refrigerator connected in violation
of the safety requirements of high-power household appliances
described in this manual is potentially dangerous.
The manufacturer is not responsible for damage to health and
property if it is caused by non-compliance with the specified
installation standards.
5. REFRIGERATOR OPERATION
BEFORE SWITCHING ON
It is necessary to connect the refrigerator to the mains three
hours after its installation. Thus, the refrigerant will be
distributed properly after transportation – this is necessary for
the proper operation of the refrigerator.
A few hours after connecting the refrigerator to the mains, You
can put products in it.
Remove the transport spacers between the compressor and the
back wall of the niche, as well as other spacers and adhesive
tapes that keep the moving parts of the device from shifting.
If the device has a protective coating of polymer film, carefully
remove it, taking precautions not to damage the paint or polymer
coating of the parts.
DISPLAY
NORMAL
COLDERCOLD
(summer) (winter)
Freezer
Control
1
2
3
When you turn on the refrigerator for the
first time, the display (including all
indicators) will light up at maximum
brightness for three seconds, after which
only the backlight of the activated mode
will remain on.
1. Temperature selection button
2. Button to activate the «Super cool»
mode
3. Indicators of the temperature regime of
the refrigerating chamber (2, 3, 4, 6, 8 °С)
To change the temperature mode, use the
button (1). Select the required temperature
by successive pressing of the button, after
15 seconds the mode is activated.
If you need to quickly cool the zero zone,
use the «Super cool» mode. To activate
the mode, press the «Super» button. The
indicator will turn on, confirming the activation of the mode. After
2.5 hours, the mode will turn off.
USING THE FREEZER
NORMAL
COLDERCOLD
(summer) (winter)
Freezer
Control
The freezer temperature control is located at the bottom of
the refrigerator compartment, behind the bottom «zero zone»
container.
Using the temperature controller, you can select the mode in
accordance with the requirements:
«COLD» - the mode of increased freezing. It is used in summer
time, or at an ambient temperature above 35 °C.
«COLDER» - reduced freezing mode. It is used in winter time, or at
an ambient temperature below 10 °C.
«NORMAL» - the average value between the «COLD» and
«COLDER» modes. Typically used at ambient room temperature.
In order to ensure the best storage conditions for products, follow
the recommendations below. Products intended for freezing and
storage in the freezer should be carefully packed to avoid the
formation of excessive frost.
–Preferably, the products placed inside the freezer should not
come into contact with the back and side walls.
