20
Problem Probable Causes
The appliance is not working
• Ensure that the power cable is properly connected to the electric socket.
• The ambient temperature is too low. Try to set a lower (colder) temperature.
• It is normal for the freezing chamber not to work during automatic defrosting or for a short time after refrigerator
startup to protect the compressor.
Unpleasant smell in the refrigerator Cleaning is probably required. Smells may come from foods, containers, packaging, etc.
Noise in the refrigerator
The following noises are normal:
• noise of the operating compressor;
• air circulation noise caused by the small fan in the freezing chamber or by other refrigerator components;
• bubbling noise similar to that of boiling water;
• crackling noises during automatic defrosting;
• clicking noise before compressor startup.
Motor operates continuously
The noise of the operating motor is normal in the following cases:
• the temperature is set too low;
• a large quantity of warm food has recently been placed in the refrigerator;
• ambient temperature too high;
• the door has been open for a long time or opened too often;
• first startup of the refrigerator or restart after a long break.
Layer of frost inside the refrigerator Ensure that the food does not impede air circulation. Check that the door is tightly closed.
Temperature in the refrigerator too
high
The door has probably been left often, or something is preventing the door from closing, the refrigerator is installed too
close to adjacent walls, electric appliances, etc.
Temperature in the refrigerator too
low Set a higher temperature on the control panel.
The door is hard to close Check the installation gradient of the refrigerator. The front edge of the refrigerator should be higher than the back edge
by max. 10 to 15mm to provide sufficient gravity for door closing.
Internal illumination not working
• LED lamp damaged. Replace the bulb.
• The light has been turned off by the control system since the door has been open for a long time. Close the door and
open it again to re-activate the function.
ATTENTION!
This refrigerator contains a minor quantity of R600a grade refrigerant which is practically environmentally safe; however it is a flammable gas. In case of a leak it
can cause eye irritation or ignite.
9. SPECIFICAIONS
Climate class SN/N/ST/T
Electrical Safety Class I
Volume: Full/refrigerator/freezer, l 606/365/241
Power supply voltage 220-240 V ~50 Hz
Maximum power, W 140
Freezing capacity, kg/24h 10,5
Rated current, A 1,45
Noise level, dB 37
Daily energy consumption, kWh/24h 1,260
Annual energy consumption, kWh/a 460
Internal illumination lamp, W 6
Energy consumption class А+
Refrigerant R600а (70 g)
Net/Gross weight, kg 103/113
Dimensions: WхDхH, mm 960x635x1912
Compressor type Inverter
10. DISPOSAL
Upon expiry of its service life the appliance can be disposed of separately from
ordinary domestic waste. You can turn it over to a specialized electric and
electronic appliance disposal and recycling centre.
11. CERTIFICATION DATA, GUARANTEE
The service life of this item is 10 years since the date of sale to the end user,
provided the item will be used in strict accordance with the present manual and
the applicable technical standards. Upon expiry of the service life please contact
the nearest authorized service centre for suggestions as to further operation of
the appliance. The manufacturing date of the appliance is integrated into the
serial number (digits 2 and 3 - year, digits 4 and 5 - month of manufacture). If any
questions related to appliance maintenance should arise, or if the appliance has
malfunctions, apply to the CENTEK TM Authorized Service Center. The address of
the service center can be found on the website https://centek.ru/servis. Service
support contacts: Phone: +7 (988) 24-00-178, VK: vk.com/centek_krd. General
Service Center: OOO «Larina-Servis», Krasnodar, Phone: +7 (861) 991-05-42.
The product has the Certificate of Conformity No ЕАЭС RU С-CN.ВЕ02.В.04729/23
of 07.02.2023.
