Centek CT-1746
Данная инструкция на русском языке предназначена для холодильника Centek CT-1746, описывает принцип работы и основные моменты эксплуатации устройства. Перед первым включением рекомендуется внимательно изучить данное руководство.
Инструкция для холодильника представлена в формате PDF, который поддерживается на всех современных устройствах, так что сложностей с открытием файла возникнуть не должно. Но если открыть документ не получается, установите любую программу для чтения PDF файлов, например Acrobat Reader.
Чтобы распечатать инструкцию, нужно ее сначала скачать, для этого кликните по кнопке «Скачать инструкцию», файл откроется в новой вкладке, затем нажмите комбинацию клавиш Сtrl + P и из открывшегося диалогового окна, отправьте документ на печать.
19
If the button is not pressed for 3 minutes, the child lock function will be turned
on automatically.
Exiting the child lock function manually:
To disable the child lock function, press and hold the OK button for 3 seconds.
DOOR OPENING SIGNAL
If the refrigerator door is open for more than 3 minutes, a continuous beep will
sound, which can be turned off by pressing any button, but will be resumed after
3 minutes if the door remains open. The alarm will not work until the refrigerator
door is closed.
POWER-OFF MEMORY
In the event of a power failure, the refrigerator will maintain the operating state
set before the power outage, when the power supply is restored.
POWER-ON DELAY
In order to protect the refrigerator compressor from damage in the event of a
short-term power outage (i.e. for less than 5 minutes), the compressor will not
start immediately after the power is turned on.
OVERHEATING ALARM (ONLY AFTER POWER OUTAGE)
When the power is turned on, if the temperature of the freezer sensor exceeds
-10 °C, the corresponding indicator and temperature start flashing. The
temperature of the freezer, when it is turned on, can be displayed by pressing
any button. And the normal display is restored after 10 seconds or by pressing
any button again.
FAULT SIGNAL
If the values E0, E1, EH, EC etc. are displayed on the control panel, this indicates
a malfunction of the refrigerator. In this case, please contact a service center
specialist for troubleshooting.
6. ERROR CODE TABLE
Error code Malfunction
E0 Malfunction of the refrigerator sensor
E0 Malfunction of the freezer sensor
E1 Malfunction of the freezer evaporator sensor
EC Communication error between the main board and the control board
EH Malfunction of the ambient temperature sensor
7. MAINTENANCE AND CARE
When cleaning or maintaining the refrigerator, first turn off the power by
removing the plug from the socket. Empty the chambers of food. Use neutral
detergents. Never use abrasive detergents, alkaline products, organic acids and
hot water as this may damage the paintwork. Do not use sharp or metal objects
as this may damage the refrigerator.
The door seal gets dirty easily and needs to be washed more often.
If you do not use the refrigerator for a long time, remove the plug from the socket,
defrost, wash and dry the refrigerator.
8. TROUBLESHOOTING TABLE
In case of improper operation or a malfunction, please study the following section before contacting an authorized service center. In some cases you may be able to
solve the problem yourselves.
Problem Probable Causes
The appliance is not working
• Ensure that the power cable is properly connected to the electric socket.
• The ambient temperature is too low. Try to set a lower (colder) temperature.
• It is normal for the freezing chamber not to work during automatic defrosting or for a short time after refrigerator
startup to protect the compressor.
Unpleasant smell in the refrigerator Cleaning is probably required. Smells may come from foods, containers, packaging, etc.
Noise in the refrigerator
The following noises are normal:
• noise of the operating compressor;
• air circulation noise caused by the small fan in the freezing chamber or by other refrigerator components;
• bubbling noise similar to that of boiling water;
• crackling noises during automatic defrosting;
• clicking noise before compressor startup.
Motor operates continuously
The noise of the operating motor is normal in the following cases:
• the temperature is set too low;
• a large quantity of warm food has recently been placed in the refrigerator;
• ambient temperature too high;
• the door has been open for a long time or opened too often;
• first startup of the refrigerator or restart after a long break.
Layer of frost inside the refrigerator Ensure that the food does not impede air circulation. Check that the door is tightly closed.
Temperature in the refrigerator too
high
The door has probably been left often, or something is preventing the door from closing, the refrigerator is installed too
close to adjacent walls, electric appliances, etc.
Temperature in the refrigerator too
low Set a higher temperature on the control panel.
The door is hard to close Check the installation gradient of the refrigerator. The front edge of the refrigerator should be higher than the back edge
by max. 10 to 15mm to provide sufficient gravity for door closing.
Internal illumination not working
• LED lamp damaged. Replace the bulb.
• The light has been turned off by the control system since the door has been open for a long time. Close the door and
open it again to re-activate the function.
