Centek CT-1746
Данная инструкция на русском языке предназначена для холодильника Centek CT-1746, описывает принцип работы и основные моменты эксплуатации устройства. Перед первым включением рекомендуется внимательно изучить данное руководство.
Инструкция для холодильника представлена в формате PDF, который поддерживается на всех современных устройствах, так что сложностей с открытием файла возникнуть не должно. Но если открыть документ не получается, установите любую программу для чтения PDF файлов, например Acrobat Reader.
Чтобы распечатать инструкцию, нужно ее сначала скачать, для этого кликните по кнопке «Скачать инструкцию», файл откроется в новой вкладке, затем нажмите комбинацию клавиш Сtrl + P и из открывшегося диалогового окна, отправьте документ на печать.
18
than 100mm on both sides and more than 50mm on the back of the refrigerator.
But since the cooling plate is located at the bottom, and the opening angle of
the doors allows you to install the refrigerator close to the walls, the minimum
allowable distance from the refrigerator to the walls is 4 mm.
–Do not place the appliance near heat sources.
–Do not install the refrigerator so that it is exposed to direct sunlight or near
heat sources (kitchen ovens, cookers, fireplaces, etc.).
4.2. LEVELING
It is important that the refrigerator is installed on a level surface for efficient
operation. After placing the refrigerator at its permanent location adjust its
position by turning the adjustable front feet. The refrigerator should not be
slanted backwards by more than 5°.
4.3. CONNECTING TO POWER SUPPLY
The refrigerator complies with Class 1 requirements for protection against
electric shock and is connected to the power supply grid by a two-pole plug with
an earthing contact. Before connecting to power supply ensure that:
–the grid voltage corresponds to that indicated on the data plate located on the
back side of the refrigerator;
–the earthing contact of the electric socket is connected to an earthing
conductor of the mains cable (the earthing conductor should have a minimum
rating of 10 A);
–the power socket and plug should be of the same type; if the plug does not fit
the socket the latter should be replaced with one compatible with the plug
(this work should be performed by a skilled electrician).
The refrigerator should be placed so that you would always have access to
the power socket. A refrigerator improperly connected to power supply, i.e.
incompliant with the requirements for powerful home appliances set forth in
this manual, is potentially dangerous. The manufacturer shall not be made liable
for damage to human health and property if such damage is caused by non-
observance of the installation requirements specified herein.
5. OPERATING THE REFRIGERATOR
5.1. BEFORE TURNING ON
After installing the refrigerator please wait for approx. three hours before
connecting it to power supply. This way you will allow the refrigerant to be
properly distributed: this is necessary for proper operation of the refrigerator.
You will be able to place food in the refrigerator within a few hours after
connecting it to power supply. Remove the transportation inserts between the
compressor and the back wall of the niche, as well as all other inserts and
adhesive tape preventing the movable parts of the appliance from displacement
during transportation.
If the appliance is covered in a protective polymer film, carefully remove it, taking
precautions not to damage the paint or polymer coatings in the components.
5.2. INITIAL OPERATION
DISPLAY
When the refrigerator is powered on, the display screen is displayed for 5
seconds.
After closing the refrigerator door, the display will automatically turn off if no
button is pressed for 3 minutes.
When the display is turned off, it lights up when the refrigerator door is opened
or any button is pressed.
The following button operations are valid only if the buttons are unlocked and
lit on the display.
SETTING THE TEMPERATURE IN THE REFRIGERATOR
Press the REFRIGERATOR button to select the refrigerator area, and the whole
digit on the display will start flashing, then press the REFRIGERATOR button to
adjust the whole value, then press OK to confirm the setting. Then the decimal
digit will start flashing. Press the FRIDGE button to adjust the decimal value,
finally after that press OK to confirm the setting.
The temperature conditions of the refrigerator change as follows:
5 °C => 6 °C => 7 °C => 8 °C => OFF => 2 °C => 3 °C => 4 °C => 5 °C.
OFF means turning off the refrigerator. When the OFF value is selected, the
refrigerator will turn off, the «°C» icon will go out.
ATTENTION! Before enabling this feature, be sure to remove all products from the
fresh food compartment.
SETTING THE TEMPERATURE IN THE FREEZER
Press the FREEZER button to select the refrigerator area, and the whole digit on
the display will start flashing, then press the FREEZER button to adjust the whole
value, then press OK to confirm the setting. Then the decimal digit will start
flashing. Press the FREEZER button to adjust the decimal value, finally after that
press OK to confirm the setting.
The temperature conditions of the refrigerator change as follows:
-18 °C => -17 °C => -16 °C => -24 °C => -23 °C => -22 °C => -21 °C => -20 °C => -19 °C
=> -18 °C.
SETTING UP A TEMPERATURE CONTROLLED CHAMBER
Press the Variable button to adjust the temperature in the temperature-
controlled chamber (7). Select the desired temperature.
Temperature conditions in the refrigerator compartment change as follows:
-6 °C => -5 °C => -4 °C => -3 °C => -2 °C => -1 °C => 0 °C => 1 °C => 2 °C = > 3 °C => 4 °C =>
5 °C => OFF => -20 °C => -19 °C => -18 °C => -17 °C => -16 °C => - 15 °C => -14 °C => -13 °C
=> -12 °C => -11 °C => -10 °C => -9 °C => -8 °C => -7 ° C => -6 °C.
Press and hold the OK button for 5 seconds to confirm the setting. In this case, the
current mode indicator will stop blinking.
When the refrigerator temperature is set to OFF, the setting mode is disabled.
Note: Be sure to remove all food in the temperature-controlled compartment
before setting up.
ECO FUNCTION
When the ECO function is enabled, the temperature in the refrigerator will
be set to 5 °C, and in the freezer - to -18 °C, which guarantees the storage of
products in the best temperature range, as well as more efficient operation of
the refrigerator.
In ECO mode, the temperature in the refrigerator and freezer does not change.
Activation of ECO mode:
Press the function selection button (12) until the ECO indicator starts flashing,
then press and hold the OK button for 5 seconds to confirm the setting, the ECO
indicator lights up continuously.
Exiting ECO mode:
While the ECO function is active, press the function selection button (12) until the
ECO indicator flashes, then press and hold the OK button for 5 seconds to confirm
the setting and turn off the ECO function, the ECO indicator turns off, and the
temperature in the chambers is restored to the one that was set before switching
on ECO functions (not in functional state).
NOTE: During the activation of the «Fast Freezing» or «Fast Cooling» function, the
ECO function is automatically turned off.
«FAST FREEZING» FUNCTION
When the «Fast Freezing» function is enabled, the temperature in the freezer
will be set to -32 °C. After 26 hours, the function will automatically turn off. A
rapid decrease in the temperature in the freezer is useful to prevent the loss of
nutritional properties of products and preserve their freshness.
In the «Fast Freezing» mode, the temperature in the freezer does not change.
Activating the «Fast Freeze» mode:
Press the function selection button (12) until the «Fast Freeze» indicator flashes,
then press and hold the OK button for 5 seconds to confirm the setting, the «Fast
Freeze» indicator is lit continuously.
Exiting the «Fast Freeze» mode:
After the total period of operation of 26 hours, the «Fast Freeze» function will
automatically turn off.
During the activity of the «Fast Freeze» function, press the function selection
button (10) until the «Fast Freeze» indicator flashes, then press and hold the OK
button for 5 seconds to confirm the setting, the «Fast Freeze» indicator turns off,
the function turns off.
NOTE: During the activation of the ECO function, the «Quick Freeze» function is
automatically disabled.
BLOCKING FROM CHILDREN
When the child lock function is enabled, the temperature and functions do not
change to prevent incorrect operation.
