Centek CT-1733
Данная инструкция на русском языке предназначена для холодильника Centek CT-1733, описывает принцип работы и основные моменты эксплуатации устройства. Перед первым включением рекомендуется внимательно изучить данное руководство.
Инструкция для холодильника представлена в формате PDF, который поддерживается на всех современных устройствах, так что сложностей с открытием файла возникнуть не должно. Но если открыть документ не получается, установите любую программу для чтения PDF файлов, например Acrobat Reader.
Чтобы распечатать инструкцию, нужно ее сначала скачать, для этого кликните по кнопке «Скачать инструкцию», файл откроется в новой вкладке, затем нажмите комбинацию клавиш Сtrl + P и из открывшегося диалогового окна, отправьте документ на печать.
21 22
two-pole outlet with a grounding contact.
–Before connecting to the mains, make sure that:
–The mains voltage corresponds to the data indicated on the
special plate on the back of the refrigerator;
–The grounding contact of the electrical outlet is connected to
the grounding wire of the power supply cable of the electrical
network (the connecting wire must be designed for a current of
at least 10 A);
–The socket and plug are of the same type; if the plug does
not fit into the outlet, the outlet should be replaced with the
corresponding plug of the power cord (the work must be
performed by a qualified electrician).
The refrigerator must be installed in such a way that you always
have access to an outlet. A refrigerator connected in violation
of the safety requirements of high-power household appliances
described in this manual is potentially dangerous.
The manufacturer is not responsible for damage to health and
property if it is caused by non-compliance with the specified
installation standards.
5. REFRIGERATOR OPERATION
BEFORE SWITCHING ON
It is necessary to connect the refrigerator to the mains three
hours after its installation. Thus, the refrigerant will be distributed
properly after transportation – this is necessary for the proper
operation of the refrigerator.
A few hours after connecting the refrigerator to the mains, You can
put products in it.
Remove the transport spacers between the compressor and the
back wall of the niche, as well as other spacers and adhesive
tapes that keep the moving parts of the device from shifting.
If the device has a protective coating of polymer film, carefully
remove it, taking precautions not to damage the paint or polymer
coating of the parts.
DISPLAY
NORMAL
COLDERCOLD
(summer) (winter)
Freezer
Control
1
2
3
When you turn on the refrigerator for the
first time, the display (including all
indicators) will light up at maximum
brightness for three seconds, after which
only the backlight of the activated mode will
remain on.
1. Temperature selection button
2. Button to activate the «Super cool» mode
3. Indicators of the temperature regime of
the refrigerating chamber (2, 3, 4, 6, 8 °С)
To change the temperature mode, use the
button (1). Select the required temperature
by successive pressing of the button, after
15 seconds the mode is activated.
If you need to quickly cool the zero zone, use
the «Super cool» mode. To activate the mode,
press the «Super» button. The indicator will
turn on, confirming the activation of the mode. After 2.5 hours, the
mode will turn off.
Problem Cause
Long-term operation of
the compressor
–The compressor works longer in summer
when the ambient temperature is higher;
–There are too many products in the freezer
at the same time;
–Hot food in the refrigerator;
–Frequent opening of the refrigerator door;
–The refrigerator door is not tightly closed.
Smell –Odorous products need to be packed tightly;
–Check the products for freshness.
Does not work –The refrigerator is not connected to a power
source;
–Low voltage;
–Power outage or short circuit.
The LED-lamp does not
work
–The refrigerator is not connected to a power
source;
–The LED-lamp is damaged.
The refrigerator
door does not close
completely
–There are too many products in the
refrigerator or on the door shelves;
–The refrigerator is tilted.
Noise –The refrigerator is not aligned;
–Incorrectly installed parts;
–The refrigerator touches foreign objects (for
example, surrounding furniture);
–The characteristic sounds of switching
on the thermostat and compressor are
normal sounds, during the operation of the
electrical equipment of the device.
ATTENTION!
This refrigerator contains a small amount of refrigerant R600a,
which is practically safe for the environment, but at the same time
is a combustible gas. In case of leakage, the refrigerant may cause
eye irritation or ignite.
8. SPECIFICAIONS
Model СТ-1732 СТ-1733
climate class N/ST/T
Volume: Full/refrigerator/freezer, l 302/224/78 360/276/84
Power supply voltage 220-240 V~ 50 Hz
Maximum power, W 100 150
Current, А 0.8 0.7
Noise level, dB 40 41
Electricity consumption, kW/24 h 0.8 0.641
Internal illumination lamp, W 2
Energy consumption class А+ А++
Refrigerant R600a (37 g) R600a (40 g)
Net weight, kg 61 65
Dimensions: w/d/h, mm 595/630/1880 595/635/2010
USING THE FREEZER
NORMAL
COLDERCOLD
(summer) (winter)
Freezer
Control
The freezer temperature control is located at the bottom of
the refrigerator compartment, behind the bottom «zero zone»
container.
Using the temperature controller, you can select the mode in
accordance with the requirements:
«COLD» - the mode of increased freezing. It is used in summer
time, or at an ambient temperature above 35 °C.
«COLDER» - reduced freezing mode. It is used in winter time, or at
an ambient temperature below 10 °C.
«NORMAL» - the average value between the «COLD» and «COLDER»
modes. Typically used at ambient room temperature.
In order to ensure the best storage conditions for products, follow
the recommendations below. Products intended for freezing and
storage in the freezer should be carefully packed to avoid the
formation of excessive frost.
–Preferably, the products placed inside the freezer should not
come into contact with the back and side walls.
–For proper storage and ease of subsequent defrosting, place the
products in small portions.
–Do not place full glass containers with freezing liquids in the
freezer for a long time, especially if.
–They contain tightly sealed effervescent or carbonated drinks.
The liquid, crystallizing, can destroy the container.
–Do not put liquids in containers without a lid in the freezer, in
order to avoid an increase in humidity, because this leads to an
increase in temperature.
6. MAINTENANCE AND CARE
When cleaning or maintaining the refrigerator, first turn off the
power by removing the plug from the socket. Empty the chambers
of food. Use neutral detergents. Never use abrasive detergents,
alkaline products, organic acids and hot water as this may
damage the paintwork. Do not use sharp or metal objects as this
may damage the refrigerator.
The door seal gets dirty easily and needs to be washed more often.
If you do not use the refrigerator for a long time, remove the plug
from the socket, defrost, wash and dry the refrigerator.
7.TROUBLESHOOTING
In case of unsatisfactory operation of the refrigerator or
malfunction, study this section before contacting an authorized
service center. In some cases, you can fix the problems yourself.
7. DISPOSAL
Upon expiry of its service life the appliance can be disposed of
separately from ordinary domestic waste. You can turn it over
to a specialized electric and electronic appliance disposal and
recycling centre.
8. CERTIFICATION DATA, GUARANTEE
The service life of this item is 10 years since the date of sale to
the The service life of this item is 5 years since the date of sale to
the end user, provided the item will be used in strict accordance
with the present manual and the applicable technical standards.
Upon expiry of the service life please contact the nearest
authorized service centre for suggestions as to further operation
of the appliance. The manufacturing date of the appliance is
integrated into the serial number (digits 2 and 3 - year, digits
4 and 5 - month of manufacture). If any questions related to
appliance maintenance should arise, or if the appliance has
malfunctions, apply to the CENTEK TM Authorized Service Center.
The address of the service center can be found on the website
https://centek.ru/servis. Service support contacts: Phone: +7 (988)
24-00-178, VK: vk.com/centek_krd. General Service Center: OOO
«Larina-Servis», Krasnodar, Phone: +7 (861) 991-05-42.
The product is provided with the Certificate of Conformity No
ЕАЭС RU C-RU.АЯ46.В.24760/22 of 08.04.2022.
9. MANUFACTURER AND IMPORTER INFORMATION
Made to order of: OOO «Larina-Elektroniks». Address: Russia,
350080 Krasnodar, ul. Demusa, 14. Phone: +7 (861) 2-600-900.
DEAR VALUED CONSUMER!
The warranty period is 36 months for the device and 60 months
for the compressor from the date of sale to the end user. With this
Warranty Card the Manufacturer confirms the proper condition of
the appliance and undertakes to repair, free of charge, all defects
caused by the Manufacturer’s default.
GUARANTEE MAINTENANCE TERMS
1. The guarantee shall be valid if the following documentation
conditions are observed:
–The original Warranty Card shall be filled out correctly and
clearly, indicating the of appliance model, serial number and
sale date, the stamp of the seller company and signature of its
representative shall be available, as well as the stamps on each
coupon and the buyer’s signature in the Warranty Card.
The Manufacturer reserves the right to reject guarantee
maintenance if the buyer fails to provide the abovementioned
documents or if the information contained therein is incomplete,
illegible or ambiguous.
2. The guarantee shall be valid if the following operation conditions
are observed:
–the appliance is used in strict accordance with the present
manual;
–the safety rules and requirements are observed.
3. The guarantee does not apply to regular maintenance, cleaning,
installation and setup of the appliance at the owner’s location.
4. The guarantee does not apply in the following cases:
–mechanical damage;
–normal wear of the appliance;
