Centek CT-1232
Данная инструкция на русском языке предназначена для соковыжималки Centek CT-1232, описывает принцип работы и основные моменты эксплуатации устройства. Перед первым включением рекомендуется внимательно изучить данное руководство.
Инструкция для соковыжималки представлена в формате PDF, который поддерживается на всех современных устройствах, так что сложностей с открытием файла возникнуть не должно. Но если открыть документ не получается, установите любую программу для чтения PDF файлов, например Acrobat Reader.
Чтобы распечатать инструкцию, нужно ее сначала скачать, для этого кликните по кнопке «Скачать инструкцию», файл откроется в новой вкладке, затем нажмите комбинацию клавиш Сtrl + P и из открывшегося диалогового окна, отправьте документ на печать.
13
ATTENTION! Never submerge the appliance in water or other liquids! Do not operate the
appliance in wet environments and places where liquids may be splashed on it! Never
operate the appliance in a bathroom, near swimming pools and other sources of moisture! Do
not touch the appliance with wet hands!
ATTENTION! Never use the appliance in the state of alcoholic or narcotic intoxication or
in other conditions preventing normal perception of reality. Do not allow persons in the
abovementioned conditions or in the abovementioned circumstances use the appliance!
ATTENTION! The present manual cannot provide for all possible emergency situations that
may emerge during the operation of the appliance. The user shall take all reasonable
precautions during the use of the appliance!
2. APPLIANCE DESCRIPTION
1. Protective cap
2. Conical attachment for large citrus fruit
3. Conical attachment for small citrus fruit
4. Pulp strainer
5. Crank shaft
6. Juice collector jug
7. Base with motor unit
3. SCOPE OF SUPPLY
- Cap – 1 pc.
- Conical attachment for large citrus fruit – 1 pc.
- Conical attachment for small citrus fruit – 1 pc.
- Pulp strainer – 1 pc.
- Crank shaft – 1 pc.
- Juice collector jug – 1 pc.
- Base with motor unit – 1 pc.
- Operating Manual – 1 pc.
4. OPERATING PROCEDURE
- Take the unit out of the box and remove the packaging materials (if any).
- Wipe the housing and attachments with damp cloth.
- Thoroughly wash the cap (1), conical attachments (2, 3), strainer (4) and jug (6) in warm
water with detergent. Then rinse all these parts with clean running water and wipe dry
with a soft towel.
- Set the base on a smooth, dry, stable surface. The appliance shall be disconnected from
power supply during assembly.
- Install the jug (6) on the base (7) in such way that the motor shaft (5) is centered in the
opening of the jug (6).
- Place the strainer (4) inside the juice collector jug (6).
- If you plan to press the juice from smaller citrus fruits, install the conical attachment
(3) on the shaft.
- If you plan to press large citrus fruits, insert the attachment (3) into the attachment (2)
first. Ensure that both attachments are properly aligned with each other. Place the thus
assembled cone on the motor shaft.
- Disassemble the juicer in reverse order.
USING THE JUICER FOR JUICING CITRUS FRUIT
- Ensure that the juicer is properly assembled and connect it to power supply.
- Cut each citrus fruit to be juiced in half.
- Take a half of the fruit and carefully press it on the conical attachment (2) or (3) with the cut
section. As soon as you press the fruit down on the attachment the motor will automatically
start running and the cone will start rotating. As soon as you release the pressure the motor
will stop. Take the juiced half of the fruit from the cone and proceed with the other fruits.
- After use disconnect the power cable from the power supply socket.
Note: Press the fruit to the cone multiple times to press as much juice as possible. Warning:
do not press too hard on the conical attachment as you may block the engine. The maximum
continuous pressing time should not exceed 2 minutes. Take a 3-minute break after each 2
minutes of continuous pressing.
5. MAINTENANCE
- Clean the appliance after each use. Always disconnect the appliance from power
supply before cleaning.
- Grab the collecting jug (6) by the handle and remove from the shaft together with the
other parts by turning it clockwise. Take the accessory assembly to a wash basin
and take it apart into individual parts. Thoroughly wash all parts in warm water with
a kitchen detergent. Then rinse with clean running water and wipe dry with a soft
towel.
Note:
- We recommend washing the juicer immediately after use, before the pulp dries and
sticks to the parts. Otherwise it will be hard to remove.
- Clean the base (7) with a cloth slightly dampened with a neutral kitchen detergent
solution. After washing wipe the base (7) dry.
- Do not use abrasive cleaning agents, solvents, etc. This may damage the unit’s paint
coating.
6. SPECIFICATIONS
-Voltage: 220–240 V ~50/60 Hz
- Nominal power rating: 40 W
7. ENVIRONMENTAL PROTECTION, DISPOSAL OF THE APPLIANCE
ENVIRONMENTAL PROTECTION
The packaging and the appliance itself are made of recyclable materials. Whenever possible,
please discard those into a waste container provided for recyclable materials.
DISPOSAL
Upon expiry of its service life the appliance can be disposed of separately from ordinary
domestic waste. You can turn it over to a specialized electric and electronic appliance disposal
and recycling centre. The materials will be processed in accordance with their classification.
By turning the discarded appliance over for recycling You will make a considerable contribution
to environmental protection. You can obtain a list of electric and electronic appliance disposal
and recycling centers from Your local municipal authorities.
8. CERTIFICATION DATA, GUARANTEE
The product is certified in accordance with the Law on Consumer Rights Protection. This
appliance complies with all official national safety standards applicable to electric appliances
in the Russian Federation. The service life of this item is 5 years since the date of sale to
